GENERATOR SET AC STAMFORD TYPE ALTERNATOR 184 50HZ 60HZ SINGLE PHASE THREE PHASE

Product Item : 184 50HZ 60HZ
Category： ALTERNATOR
Stamford Type Alternator
4 poles 1500RPM 1800RPM
Three Phase Single phase
Product description：DINGOL WERNA FARADAY FARRAND ALTERNATOR WR184ES WR184E WR184F WR184G WR184H WR184J WR184K DG184ES DG184E DG184F DG184G DG184H DG184J DG184K FD1ES-4 FD1E-4 FD1F-4 FD1G-4 FD1J-4 FD1K-4
Order online

Generator Rating Table (4-pole 3-phase rating)
Model	Three Phase 50Hz 1500RPM
Power Factor	0.8		0.8		0.8		0.8		0.8		0.8		0.8		0.8		0.8
Volts
Star(W12&W13)	380		400		415		440				416		440		460		480
Delta(W12&W13)	220		230		240		254				240		254		266		277
Series Star(W11&W14)	380		400		415		440		380-416		416		440		460		480
Parallel Star(W11&W14)	190		200		208		220		190-208		208		220		230		240
Series Delta	220		230		240		254		220-240		240		254		266		277
Parallel delta	110		115		120		127		110-120		120		127		133		138.5
Winding No.	11		11		11		11		14		11		11		11		11
Rating	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW
DG184ES	20	16	20	16	20	16	15	12	25	20	24	19.2	25	20	25	20	25	20
DG184E	22.5	18	22.5	18	22.5	18	17.5	14	27.5	22	27.5	22	28.8	23	28.8	23	30	24
DG184F	27.5	22	27.5	22	27.5	22	22	17.6	32.5	26	32.5	26	34.4	27.5	34.4	27.5	35	28
DG184G	31.3	25	31.3	25	31.3	25	25	20	37.5	30	35	28	37.5	30	37.5	30	37.5	30
DG184H	37.5	30	37.5	30	37.5	30	30	24	43.5	34.8	44.3	35.4	46.9	37.5	46.9	37.5	46.9	37.5
DG184J	40	32	40	32	40	32	32	25.6	47.5	38	47.3	37.84	50	40	50	40	50	40


Generator Rating Table (4-pole 1-phase rating)
Model	Single Phase 50Hz 1500RPM												Single Phase 60Hz 1800RPM
Power Factor	0.8		0.8		0.8		1.0		1.0		1.0		0.8		0.8		0.8		1		1		1
Volts
Series	220		230		240		220		230		240		220		230		240		220		230		240
Parallel	110		115		120		110		115		120		110		115		120		110		115		120
Winding No.	05		05		05		05		05		05		06		06		06		06		06		06
Rating	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW	KVA	KW
TR184ES	12.5	10.0	12.5	10.0	12.5	10.0	14.0	14.0	14.0	14.0	14.0	14.0	15.0	12.0	15.0	12.0	15.0	12.0	18.0	18.0	18.0	18.0	18.0	18.0
TR184E	15.0	12.0	15.0	12.0	15.0	12.0	16.6	16.6	16.6	16.6	16.6	16.6	18.4	14.7	18.4	14.7	18.4	14.7	21.0	21.0	21.0	21.0	21.0	21.0
TR184F	18.5	14.8	18.5	14.8	18.5	14.8	20.0	20.0	20.0	20.0	20.0	20.0	21.9	17.5	21.9	17.5	21.9	17.5	25.6	25.6	25.6	25.6	25.6	25.6
TR184G	21.0	16.8	21.0	16.8	21.0	16.8	22.8	22.8	22.8	22.8	22.8	22.8	25.0	20.0	25.0	20.0	25.0	20.0	30.0	30.0	30.8	30.8	30.8	30.8
TR184H	25.0	20.0	25.0	20.0	25.0	20.0	27.0	27.0	27.0	27.0	27.0	27.0	31.3	25.0	31.3	25.0	31.3	25.0	35.0	35.0	35.0	35.0	35.0	35.0
TR184J	28.0	22.4	28.0	22.4	28.0	22.4	30.0	30.0	30.0	30.0	30.0	30.0	35.0	28.0	35.0	28.0	35.0	28.0	40.0	40.0	40.0	40.0	40.0	40.0
